3" Ductile Iron Twin Motor Twin Agitator Pump

Submersible Agitator Pump

Competitive Advantages & Features

Designed for Severe Service
Very High Flow Rates
High Vertical Head Pressure
Self Priming
Variable Speed & Flow
Small Portable Size, Fits in a Manhole
Anti-Clog Double Suction Technology
No Mechanical Seals
No Internal Friction
Low Maintenance Design
ce-mark
Approved

Fast Facts

  • Weight: 95 Pounds
  • Material: Ductile Iron
  • Max Water Flow: 600 GPM
  • Max Vertical Head: 350 Feet
  • Operating PSI: 2250 – 3300 PSI
  • Hydraulic Flow: 4 to 21 GPM
  • Dimensions: 29″ x 10″ x 12″

FF-3D-TA Pump Curve

3DAGTM Pump Curve

Fast Facts

  • Weight: 43 kg
  • Material: Ductile Iron
  • Max Water Flow: 2271 LPM
  • Max Vertical Head: 106 m
  • Operating Bar: 155 – 227 Bar
  • Hydraulic Flow: 15 to 79 LPM
  • Dimensions: 74cm x 25cm x 31cm

FF-3D-TA Pump Curve

FF 3D TA Pump Curve jpg

Drill Cuttings Pumping

The Fast Flow 3″ Severe Service Pump is built to be a survivor. All critical components of the pump are upgraded: including a heat-treated ductile iron impeller and volutes, hardened 17-4 drive shaft, and stainless couplings. The two efficient hydraulic gear motors are self-lubricated by the hydraulic fluid power the pump. There are absolutely no shaft bearings, no wear plates, no grease fittings, no internal impeller to housing contact, and no mechanical seals to replace in the pump.



Play Video

Pumping Applications

The FF-3D-TM-TA is designed for slurry and slurry solids pumping. The applications below represent only a fraction of what this pump can do. Call our expert sales technicians at (228) 475-2468 for more information or help with finding the perfect pump for your needs.



Refinery coke pit pumping

Oil rig well cellar pumping

Refinery tank cleanouts

Mud slurry pumping

Reserve pit pumping

Petroleum tank cleaning

Heavy solids pumping

Oil spill response

Contaminated waste pumps

Salvage jetting operations

Agriculture pond aeration

Coal mine dewatering

Rail cars cleaning

Diesel and jet fuel pumping

Oil well blowout cleanup

Drill mud preparation
